CS 80AH 12V lithium lifepo4 starter battery 1500a (s)


Price:
Sale price€409,00 EUR Regular price€490,00 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

Please inform yourself before ordering from your vehicle manufacturer whether retrofitting is possible!

Not suitable for Euro6 vehicles.



New 80Ah lithium lifepo4 auto starter battery in the standard housing

With the new LIFEPO4 lithium-iron phosphate X-Power starter battery from CS batteries, you have the option for the first time to exchange your previous lead, or yellow battery of your car 1 & 1 for a Lifepo4 starter battery. We offer you the latest lithium batteries technology ready for installation in a standard battery housing. An exchange can therefore be easily and quickly possible without any further changes on your vehicle.

The standardized SAE pole connections also fit on the X-Power lithium battery and are mounted in no time at all.

Our X-Power starter batteries come fully loaded and start your vehicle immediately after installation.

To protect lithium technology, a BMS (Battery management system) is installed in the battery. This BMS protects your battery from overvoltage, over temperature, compensates for the cells when charging and prevents a deep discharge of the battery.

Due to the extremely low internal resistance of LIFEPO4 batteries, in contrast to AGM batteries, the battery is highly current. This allows the vehicle's alternator to charge the battery with higher electricity in a shorter time.

The new X-Power lithium starter battery replaces lead, or yellow batteries up to 280AH.

They also have simple and inexpensive weight savings compared to conventional 280Ah lead or gel batteries of up to 80kg.



Top features:

  • Latest A123 lithium-iron phosphate cell technology gen3
  • 1 & 1 interchangeable against Hermenic Lead,- or yellow batteries
  • Replaces a 280Ah lead, or yellow batteries
  • Full-fledged automotive starter battery, plug & play!
  • Simple connection with SAE car clips!
  • High -powered
  • Operation on common alternator
  • Safety first, protection of the battery cells by an intelligent BMS (battery management system)
  • Overvoltage protection
  • Temperature protection
  • Single cells balancing
  • Deep discharge
  • Over 3000 cycles at 80% unloading
  • 100% maintenance -free and frost -proof
  • Enormous weight savings
  • Easy assembly through standard awe
  • Very long service life
  • Environmentally friendly, no lead, no acid
  • Recyclable!



The lithium-iron phosphate battery (LIFEPO4) is the safest from the family of lithium-ion battery types. It is high -powered, universally usable and has a low weight towards lead, gel or AGM batteries. In addition, the latest lithium iron technology offers a high degree of self-security, so that a risk of explosion is excluded even under the most extreme conditions. A 13.2V LIFEPO4 battery consists of 4 individual cells connected in series, each with 3.3V nominal voltage. A built-in battery management system (BMS) also safely protects the battery cells from damage.



LOAD

The LIFEPO4 X-Power starter battery is connected to the alternator of the car like a lead battery. The alternator controller treats and loads the LIFEPO4 starter battery as well as a lead battery, for this no change in the car or on the alternator is necessary. In the one or expanded state, the battery must be on our specialXF5 performance charger C140005 Loading.

If your vehicle is equipped with an intelligent generator control and/or recuperation, this battery is not suitable for this. We offer you suitable batteries under the category "Car / recuperation - batteries" at.



BALANCE

The X-Power battery has a built-in balancer, which perfectly compensates for the cells on each load on the switch-off voltage for maximum start power.



LIFESPAN

The LIFEP04 power cells are currently specified with over 3000 charging/unloading cycles during treatment within the specified parameters. So 4-5 times higher than common lead or gel batteries.



Advantages of our LIFEPO4 X-Power battery against lead batteries:

  • Very large weight advantage over conventional lead batteries!
  • Enormous start power with 1500a!
  • Extremely fast charging of the cells!
  • Longer lifespan, up to 10 years through the latest Lifepo4 Technology!
  • The cheapest weight tuning!



Battery management system (BMS)

A battery management system monitors and controls the individual cells of a battery and protects them from damage.

Important functions of a battery management system:

  • Overload protection
  • Deep discharge
  • Overvoltage protection
  • Active cell balancing
  • Cycling and control
  • Temperature protection of the cells
  • Temperature protection of the BMS
  • Short -circuit

Certificates:

CE: General operational safety

Unt38.3: Certified transport security in traffic

Rohs: Certified material security

Warranty: 2 years



Technical data:

Model: CSX12280-C1500A

Type:Starter battery

Nominal capacity: 80Ah

Energy content: 1024 Wh

Cell technology: Lithium-iron nanophosphate lifepo4

Cell type: A123 Systems

Replaces one: 280Ah lead-gel battery

Application: 12V starter battery, short -term high current laceration

Application in parallel circuit: No

Application Series circuit: No

Operating voltage: 10.5 - 14.6V

Nominal voltage: 13.2V

Lifespan: = 10 years

Cycling time at 80% DOD: = 3000

Loading programs: CCCV

Load closing voltage: 14.6V

Maximum charging current: 150a

Permanent enthusiasm: 150a

Starting performance (1 sec.): 1500a (s)?Discharge tension: 10.5V

Temperature range (discharge): -20 ° C to +65 ° C

Temperature range (charge): 0 ° C to +50 ° C

Temperature range (storage): -20 ° C to +65 ° C

Battery management system (BMS): Yes, installed

Balancer: Yes, active balancer

Self -discharge: 1-2% / month

Installation position: any

Connection: Standard SAE polk terminals / pole arrangement 0

Protection class: IP65 water & dust protected

Weight: 10.5kg

Dimensions (BXTXH): 355 x175 x 188 mm

Recommendation e.g. for:

6 - 12 cylinder petrol engines up to 12.0 ltr. 6 - 10

Cylinder diesel engines up to 10.0 LTR.



Scope of delivery: 1 x LIFEPO4 X-Power battery

1 x operating instructions



Minimal weight, maximum start performance, 1 & 1 interchangeable!
