Forster 300AH 12.8V LIFEPO4 Premium Battery 200a-BMS-2.0 500A Bluetooth Mess-Shunt 3840WH IP67


Price:
Sale price€2.545,41 EUR Regular price€3.090,00 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

NOVELTY!



You can find the right connection cable for the minus pole

At Frenchman Energy here And with Frenchman Marine here

The appropriate polabapter

At Frenchman Energy here And with Frenchman Marine here.


You can find more information here

Technical data

Data / order no.:

F12-300XB

EAN

4251847301126

capacity

300Ah

Replaced lead-gel-agm battery

12V/600AH

nominal voltage

12.8V

Energy content

3840Wh

Operating voltage

10.5V - 14.6V

Application in parallel circuit

Yes, any number of the same type possible in parallel!

Application of series circuit

Yes, in serial up to 24V, 36V and a maximum of 48V!

Cell technology

Lithium lifepo4

Cell type

BPC BIG-Prismatic-Power high-load cell-gradeaa

Loading programs

CCCV / iu / iuou / lead acid

Laddling tension

14.2V - 14.6V

Preservation

13.3 - 13.8V

Maximum charging current

200a

Recommended charging current

150a

Max.entladestrom / 5 sec.

400a

Permanent entertainment current

200a

Battery shutdown

10.5V

BMS Battery Management System

integrated

Remote monitoring optional

500a Bluetooth Mess-Shunt and free app

Remote monitoring/measurement shunt integrated

F12-300XB

Protection class

IP67

Cycles / lifespan at 50% DOD

>8000

Cycles / lifespan at 80% DOD

>6000

Cycles / lifespan at 90% DOD

>5000

Temperature when charging

0 ° C to +60 ° C / below 0 ° C The charging current is automatically reduced by "Cell-Frost-Control" in the BMS

Temporariness in the event of discharge

-20 ° C to +60 ° C

Recommended storage temperature

-10 ° C to 30 ° C

storage

80 - 100% loaded / Load the battery every 6 months if not used, battery

Self -discharge

1 - 2% / month

Connection

M8

Pluspol arrangement

Front right

Final pole

M8 interior thread

Preparation Shunt assembly

n/a

Emergency cutter installed

n/a

length

520mm

Width

268mm

Height

220mm

Installation position

arbitrarily, standing, lying, side, upright, head over

Canbus interface

n/a

Weight

31.5kg

guarantee

5 years

Certification

UN38.3 | MSDS | CE | Raw

Data / order no.:

F12-300X

EAN

4251847301126

capacity

300Ah

Replaced lead-gel-agm battery

12V/600AH

nominal voltage

12.8V

Energy content

3840Wh

Operating voltage

10.5V - 14.6V

Application in parallel circuit

Yes, any number of the same type possible in parallel!

Application of series circuit

Yes, in serial up to 24V, 36V and a maximum of 48V!

Cell technology

Lithium lifepo4

Cell type

BPC BIG-Prismatic-Power high-load cell-gradeaa

Loading programs

CCCV / iu / iuou / lead acid

Laddling tension

14.2V - 14.6V

Preservation

13.3 - 13.8V

Maximum charging current

200a

Recommended charging current

150a

Max.entladestrom / 5 sec.

400a

Permanent entertainment current

200a

Battery shutdown

10.5V

BMS Battery Management System

integrated

Remote monitoring optional

Optionally possible with 500a Bluetooth measurement shunt and free app

Remote monitoring/measurement shunt integrated

F12-300XB

Protection class

IP67

Cycles / lifespan at 50% DOD

>8000

Cycles / lifespan at 80% DOD

>6000

Cycles / lifespan at 90% DOD

>5000

Temperature when charging

0 ° C to +60 ° C / below 0 ° C The charging current is automatically reduced by "Cell-Frost-Control" in the BMS

Temporariness in the event of discharge

-20 ° C to +60 ° C

Recommended storage temperature

-10 ° C to 30 ° C

storage

80 - 100% loaded / Load the battery every 6 months if not used, battery

Self -discharge

1 - 2% / month

Connection

M8

Pluspol arrangement

Front right

Final pole

M8 interior thread

Preparation Shunt assembly

n/a

Emergency cutter installed

n/a

length

520mm

Width

268mm

Height

220mm

Installation position

arbitrarily, standing, lying, side, upright, head over

Canbus interface

n/a

Weight

31.5kg

guarantee

5 years

Certification

UN38.3 | MSDS | CE | Raw

Data / order no.:

F12-300X

EAN

4251847301126

capacity

300Ah

Replaced lead-gel-agm battery

12V/600AH

nominal voltage

12.8V

Energy content

3840Wh

Operating voltage

10.5V - 14.6V

Application in parallel circuit

Yes, any number of the same type possible in parallel!

Application of series circuit

Yes, in serial up to 24V, 36V and a maximum of 48V!

Cell technology

Lithium lifepo4

Cell type

BPC BIG-Prismatic-Power high-load cell-gradeaa

Loading programs

CCCV / iu / iuou / lead acid

Laddling tension

14.2V - 14.6V

Preservation

13.3 - 13.8V

Maximum charging current

200a

Recommended charging current

150a

Max.entladestrom / 5 sec.

400a

Permanent entertainment current

200a

Battery shutdown

10.5V

BMS Battery Management System

integrated

Remote monitoring optional

Optionally possible with 500a Bluetooth measurement shunt and free app

Remote monitoring/measurement shunt integrated

F12-300XB

Protection class

IP67

Cycles / lifespan at 50% DOD

>8000

Cycles / lifespan at 80% DOD

>6000

Cycles / lifespan at 90% DOD

>5000

Temperature when charging

0 ° C to +60 ° C / below 0 ° C The charging current is automatically reduced by "Cell-Frost-Control" in the BMS

Temporariness in the event of discharge

-20 ° C to +60 ° C

Recommended storage temperature

-10 ° C to 30 ° C

storage

80 - 100% loaded / Load the battery every 6 months if not used, battery

Self -discharge

1 - 2% / month

Connection

M8

Pluspol arrangement

Front right

Final pole

M8 interior thread

Preparation Shunt assembly

n/a

Emergency cutter installed

n/a

length

520mm

Width

268mm

Height

220mm

Installation position

arbitrarily, standing, lying, side, upright, head over

Canbus interface

n/a

Weight

31.5kg

guarantee

5 years

Certification

UN38.3 | MSDS | CE | Raw

GPSR Information

Hersteller
Name: FORSTER INDIVIDUAL BATTERIES
Anschrift: Commercial Street 11
PLZ, Ort: 85652, Pliening
Land: Germany
Email: info@forster-batteries.de
Web: https://www.forster-batteries.de/
