ISOTHERM 3201 Cool/freezer ITC+ 12/24V

IsothermSKU: U100X035A17161AA

Price:
Sale price€1.197,50 EUR Regular price€1.573,18 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

ISOTHERM 3201 Cool/freezer ITC+ 12/24V, air-cooled with ITC control and memory plate
The ISOTHERM ITC+ systems were developed for installation in existing cooling boxes. They are primarily intended for use on sailing boats, where the battery current is particularly valuable. The ITC+ system allows maximum cooling capacity with minimal loads on the batteries. It recognizes when excess energy is available from the generator of the boat engine and increases the speed of the compressor so that the cold storage is quickly cooled down. If excess energy is no longer available, the system reduces consumption accordingly. The NIRO cold storage can be installed at any angle high up in the cool box before it is connected to the compressor unit. The connection is made with the help of 3 m long, 6 mm thick flexible copper pipes with quick couplings. The compressor unit is so small that it can be accommodated in a storage space or in another unused place within the connection distance for cold storage. After connecting the power cable to the battery, the pre -filled cooling system is ready for operation.

Third cold compressor generation with refined ITC+ system. The new Danfoss compressor is not only more compact, but also significantly lighter and more effective. In a system without ASU, energy savings are up to 20 %compared to older compressor types. With ITC+ and other refinements, energy consumption could be reduced by up to 50 % compared to previous models. The compressor runs so quietly that we have now integrated a separate speed control for the blower, as it was better heard than the compressor. The new ITC+ system regulates compressor and fan on the smallest possible speed if they only run with battery stream.

The clear external ITC digital display shows, controls and regulates the temperature in the fridge or freezer. The good -looking user interface and a refined product interaction significantly reduce the power consumption of the device. Thanks to the built -in air sensor, the electronic control unit recognizes the actual air temperature and processes it in combination with the settings selected by the user to optimize compressor operation and thus the power consumption. All data is displayed on the service display.

12/24 V air -cooled Danfoss compressor BD35F 280 x 160 x 175 mm
AC / DC kit optional for a comprehensive power supply (12/24 V, 230/115 V and 50 /60 Hz)
Simple installation thanks to click-on system
100l cooling volume/ 35l freezer volume
2L memory plate (length x width x height) 300 x 210 x 60 mm
Weight 14 kg
Isotherm Smart Energy Control
Temperature setting
Operating art setting of the compressor - ITC / ECO / cooling mode
Special air sensor always provides precise measured values ​​and the user can choose between three different battery protection levels
