ISOTHERM VE150 cooling system 12/24V

ISOTHERM VE150 cooling system 12/24V for 150 liters of refrigerator, fast cooling capacity, very compact dimensions
The thermostat-controlled cooling units are based on a Danfoss compressor that cools a capacitor in the cooling or freezer box. Danfoss compressors are very efficient. Hermetically sealed, they work in a mixture of oil and coolant, which contributes to very calm running behavior and very little wear. Like all efficient electrical devices, the compressors used by Indel Webasto Marine work with a 3-phase system. The 3-phase voltage is generated in a small microprocessor. For tropical conditions, we recommend reducing the pit volume by 10 - 20%.
Indel Webasto Marine has succeeded in integrating different functions that control and monitor the device. This allows low power consumption. The same processor is used in the 12 V and 24 V systems and is protected against unwanted reversal. A air is guided by the capacitor using a fan. This is the traditional type of cooling. It must be ensured that cold air can be added from below and warm air can escape upwards.

Use for refrigerators, air -cooled
12/24 V Danfoss compressor
AC / DC kit optional for a comprehensive power supply (12/24 V, 230/115 V and 50 /60 Hz)
Lamella evaporator (width x height x depth) 275 x 220 x 58 mm
Weight 11 kg
Electricity consumption 550w /24h
Air -cooled Danfoss compressor BD35F, 385 x 130 x 175mm
Isotherm Smart Energy Control drastically reduces the power consumption of refrigerators
