Copy of Victron Bluesolar Mppt 100/15 12V 24V 15a - without Bluetooth #1

Victron EnergySKU: SCC110015060R

Price:
Sale price€83,18 EUR Regular price€99,96 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Victron MPPT 100/15 belongs to the large family of the Bluesolar Mppt loader and, like its big siblings, it already offers ultra-fast power tracking and can thus increase the yield of its solar system. Compared to the 75/15, this controller can process a higher PV voltage and thus regulate up to 100V DC voltage.

MPP tracker of the latest generation

Especially when the sky is covered, when the light intensity is constantly changing, an extremely fast MPPT controller improves the energy yield compared to PWM charging controls by up to 30 % and compared to slower MPPT regulators by up to 10 %. In addition, the 100/15 has some other innovative technologies.

Options for programming, data in real time and display of the course

Modern Apple and Android Smartphones, Tablets, MacBooks and other devices can be connected to the Bluetooth Smart Dongles and the MPPT or the GX Color Control via VE VE.Direct, for example. Please note the Bluetooth Smart Dongles and GX Color Control Own articles that are not included in the scope of delivery of the charge controller but can be acquired optionally from us.

Essential product features of the Bluesolar 100/15 15a 12V 24V mppt

Ultra-fast MPP tracker of the latest generation ensures the best possible yield even with a covered sky
Integrated VE.direct data communication sport for connection with additional devices such as Bluetooth Smart Dongle or the GX Color Control Panel
12V 24V systems possible
Nennladestrom 15a
220W maximum PV power at 12V, 440W at 24V systems
Load exit with 15a power and automatic load shutdown with impending subtle tension (deep discharge protection)
Integrated protection against battery reolving
Multi-level and adaptive loading algorithm
Programmable battery charging algorithm
Integrated Battery Life Algorithm extends the life of your batteries if he is active and all loads run over the load exit on the controller
Day/night-time control and lighting option
Ve.direct data communication sport integrated

Ve.direct In text mode, all important parameters are conveyed to other devices every second and thus offers the possibility of communication with additional devices such as the Bluetooth Smart Dongle or the GX Color Control Panel from Victron. The VE.Direct connection is intended for products in which complete canbus integration (VE-Direct) would cause too high costs. You can find more information about Ve.direct in our Victron brand world in the information area.

Battery Life Algorithm contributes to increasing the battery life

If the solar charging controller is unable to charge the battery within one day to its full capacity, the status of the battery constantly changes between "partially charged" and "end of discharge". This operating mode (no regular full charging) is optimal for small lead battery and especially in the case of bleed acid batteries, such irregular loading and unloading leads to damage to the battery after a few months and the lifespan partially shortens

The Battery Life Algorithm monitors the charging status of the battery and, if necessary, it takes up the threshold every day to separate the load (i.e., the load is separated earlier) until the energy obtained is sufficient to charge the battery up to almost 100 %. From this point, the threshold value for switching off the load is modulated, so that the charge is almost 100 % reached about once a week.

scope of delivery

1x Victron SCC010015200R Bluesolar Mppt 100/15 12V 24V 15a loader
1x operating instructions

GPSR Information

Hersteller
Name: Victron Energy BV
Anschrift: The Palm 35
PLZ, Ort: 1351, JG Almere
Land: Netherlands
Email: sales@victronenergy.com
Web: https://www.victronenergy.com
