Copy of Victron Orion-Tr 24/24-5a (120W) #1

Victron EnergySKU: ORI242428110

Price:
Sale price€122,50 EUR Regular price€145,18 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Victron Orion-Tr 24/24-5 from Victron Energy Is an isolated DC DC voltage converter and ensures a regulated DC voltage and thus for the trouble-free operation of your DC consumers. The device converts the DC input voltage (16-35V) into a controllable 24V output voltage (20-30V) and delivers a constant permanent current of 5A, which corresponds to an output of 120W. So you can supply every 24V consumer with exactly the right voltage. With many sensitive electronics devices, compliance with the exact operating tension is essential for an impeccable function. The Orion-TR 24/24-5 also dominates the parallel circuit with identical devices and has a remote-controllable on switch.

Characteristics:
- 24V DC operating voltage, controllable output voltage 20-30V
- Can be switched in parallel with the same -type devices for increasing performance
- Remote-controllable on and off switch
- Protection class IP43
- Galvanic separation
- Wide input span area: 16V - 35V
- 120W power at 5A permanent current
- Max. 6.3a output current
- high efficiency of 87%
- 0.6 kg
- 100x113x47

Not suitable for charging batteries. Please consider the use of an Orion-Tr Smart to charge the batteries.

DC-DC DC converters of the Orion Family generate a clean output voltage in the range of 20-30V DC and the same possible line losses as well as fluctuations in battery voltage from a 24V power source.

Remote-controllable ON/OFF switches:

Due to the remote control in/out connection, no high current switch in the input cabling is no longer necessary. The remote control in/out connection can be controlled with a power saving switch or by the run/stop switch of the engine (see manual).

Can be switched in parallel to increase the output current
Unlimited many, identical devices can be switched in parallel to increase the output power.

Scope of delivery:
1x Victron Energy Ori242410110r Orion 24/24-5 DC DC converter 24V to 24V (20-30V regulable) 5A 120W
