Lapp OELFLEX© SOLAR XLS-R T 2X4 BK/RD

LappKabelSKU: 8-01-006275

Price:
Sale price€2,79 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

ÖLFLEX© SOLAR XLS-R T 2x4mm is a cross-linked high-end solar cable made in Germany. With an optimized cable design, the solar cable is slim, light and robust and saves a lot of time during installation.

The twin line can be easily separated into two lines if required. You don't need any special tools for this. Nevertheless, the connection of the two wires is extremely stable if you prefer to keep the line together.

product properties

Weather and UV resistant according to HD 605/A1 Ozone resistant according to EN 50396 Halogen-free and flame-retardant Good notch and abrasion resistance XLS-R T= X-Linked Standard-Reduced Twin Proven electron beam crosslinked quality

Standard references / approvals

Also available as a TÜV PV1-F certified version on request - ideal for off-grid PV systems

application areas

Ideal for off-grid PV systems. Gable and flat roof photovoltaic systems. Photovoltaic or solar field systems. Flexible or building-integrated PV systems

To use

Easily separable into two individual lines. Reduced outer diameters enable space and weight-saving installation. Robust against mechanical impact. Reduction in the spread of fire and the formation of toxic smoke gases in the event of a fire. Exact quantity control when laying by means of meter markings on the cable sheath

Construction

Fine-wire, tinned copper conductor. Wire insulation made of radiation-crosslinked copolymer. Outer jacket made of radiation-crosslinked copolymer. Outer sheath colour: Black Cores connected in parallel with separator

Technical specifications

Wire identification code: black / red blue / red Classification: ETIM 5.0 Class ID: EC001578 ETIM 5.0 Class Description: Flexible cable Conductor structure: Finely stranded according to VDE 0295, Class 5 / IEC 60228 Class 5 Minimum bending radius: Fixed installation: 4 x Outer diameter Rated voltage: AC U0/U : 600/1000 V DC U0/U : 900/1500 V Max. permissible system voltage: DC 1.8 kV (phase-phase, ungrounded system) Test voltage: AC 6500 V Temperature range: 40° C to +100°C max. conductor temperature

ÖLFLEX© SOLAR XLS-R T 2x4mm is a cross-linked high-end solar cable made in Germany. With an optimized cable design, the solar cable is slim, light and robust and saves a lot of time during installation.

The twin line can be easily separated into two lines if required. You don't need any special tools for this. Nevertheless, the connection of the two wires is extremely stable if you prefer to keep the line together.

product properties

Weather and UV resistant according to HD 605/A1 Ozone resistant according to EN 50396 Halogen-free and flame-retardant Good notch and abrasion resistance XLS-R T= X-Linked Standard-Reduced Twin Proven electron beam crosslinked quality

Standard references / approvals

Also available as a TÜV PV1-F certified version on request - ideal for off-grid PV systems

Areas of applicationv

Ideal for PV off-grid systems Gable and flat roof photovoltaic systems Photovoltaic or solar field systems Flexible or building-integrated PV systems

To use

Can be easily separated into two individual cables Reduced outer diameters enable space and weight-saving installation Robust against mechanical effects Reduction in the spread of fire and the formation of toxic smoke gases in the event of a fire Exact quantity control when laying by means of meter markings on the cable sheath

Construction

Fine-wire, tinned copper conductor Core insulation made of radiation-crosslinked copolymer Outer sheath made of radiation-crosslinked copolymer Outer sheath colour: black Cores connected in parallel with separator

Delivery time: 1-3 working days

Technical specifications

Wire identification code: black / red blue / red Classification: ETIM 5.0 Class ID: EC001578 ETIM 5.0 Class Description: Flexible cable Conductor structure: Finely stranded according to VDE 0295, Class 5 / IEC 60228 Class 5 Minimum bending radius: Fixed installation: 4 x Outer diameter Rated voltage: AC U0/U : 600/1000 V DC U0/U : 900/1500 V Max. permissible system voltage: DC 1.8 kV (phase-phase, ungrounded system) Test voltage: AC 6500 V Temperature range: 40° C to +100°C max. conductor temperature

data sheet

Generally
item number 8-01-006275
Manufacturer part number 0023984
product type solar cable
Manufacturer Lapp cable
Characteristics Weather / UV resistance (according to HD 605/A1)
material copper
Operating ambient temperature range Permanently laid: -40°C to +100°C max. conductor temperature
ladder construction Finely stranded according to VDE 0295
copper content 76.8kg/km
Conductor cross-section (mm²) 4mm²
test voltage AC 6500V
core colours Black red
number of cores 2
classification ETIM 5.0 Class Description: Flexible line, ETIM 5.0 Class ID: EC001578
Dimensions (LxWxH) (WxH) 10.7 x 5.2mm
weight 128kg/km
EAN 0797337909976
