Offgridtec® ETFE-AL 120W V2 semi-flexible 18V solar panel

OffgridtecSKU: 3-01-018430

Price:
Sale price€89,00 EUR Regular price€137,77 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The semi-flexible ETFE-AL 120W V2 solar panel from

Offgridtec (MPN 018430) is based on a groundbreaking material composition (aluminum-ETFE) and is equipped with highly efficient mono cells. The output voltage is 18V DC, which makes it very interesting for a wide variety of application scenarios. It is also walkable and significantly less slippery than its predecessors, making it the perfect choice for the marine and mobile sectors. Power is supplied by state-of-the-art solar cells, which, thanks to the latest technology, boast remarkable cell efficiency and also stand out from the crowd with low power degradation values. This is the new and improved version of the popular ETFE-AL 120W solar panel (3-01-011050). Thanks to state-of-the-art manufacturing, it guarantees consistently high quality and performance with a maximum service life.

About the 120W ETFE AL V2 solar module

  • 2 superimposed ETFE layers
  • improved slip resistance
  • Long-term higher yields due to better light transmission
  • Solid ETFE front provides protection against hail
  • resistant to salt water
  • works with 5 busbar technology
  • integrated AL backsheet

ETFE layers

On the front of the module, two superimposed ETFE layers provide solid protection for the internal cells and high light output for many years. Thanks to a new structure of the outermost layer, slip resistance has been significantly improved, making the module safe to walk on. Higher long-term yields are achieved thanks to better light transmission and significantly less clouding of the transparent ETFE front layers compared to conventional solar modules with different front coatings. The solid ETFE front offers strong protection against hail and makes the module completely resistant to salt water. The integrated aluminum backsheet virtually eliminates the risk of cell cracks due to incorrect handling or installation. The series is equipped with the highest quality solar cells, which offer a high cell efficiency of 22.3 percent.

5 Busbar technology

Power management is handled by five busbars. This advanced technology utilizes five electrical conductors (busbars) to manage power. This enables reliable throughput, even at high currents, while minimizing heat loss. Efficient power distribution ensures solid performance of the solar modules, resulting in improved overall efficiency and higher yields.

Monocrystalline solar cells

Monocrystalline solar panels are an advanced form of photovoltaic module constructed from a single crystal lattice. This crystalline structure enables greater efficiency in converting sunlight into electrical energy compared to other types of solar panels. Monocrystalline cells are characterized by their uniform structure, which allows for more efficient movement of charge carriers. This leads to better performance, especially in situations with limited space, as monocrystalline modules have a higher power density.

Technical features of ETFE-AL

  • Power (Pmax): 120 Wp
  • Voltage (Vmp): 18.8 V
  • Max. current (pulse): 6.39 A
  • Short-circuit current (Isc): 6.70 A
  • Open circuit voltage (Voc): 22 V
  • Max. system voltage: 200 V
  • Dimensions (LxWxH): 1120 x 580 x 4 mm
  • Operating temperature range: -40°C - 85°C
  • Module efficiency: 22.3%
  • integrated bypass diodes
  • Material composition: aluminum, ETFE
  • walkable: Yes
  • Bendable: max. 10° (L)
  • Weight: 4.19kg
  • Scope of delivery:

    1x Offgridtec ETFE-AL 120W V2 semi-flexible 18V solar module
