Siemens 5SU1356-6KK10 RCCB 2-pole 10A 0.03A 230V

SiemensSKU: 6227498270893

Price:
Sale price€39,90 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

Technical details
frequency 50Hz
Connectable conductor cross-section stranded 0.75 | 35.0
number of poles (total) 2
Energy Limit Class 3
Rated breaking capacity according to EN 61009 6.0
Rated breaking capacity according to IEC 60947-2 15.0
Rated switching capacity Icn according to EN 61009-1 6.0
voltage type AC
Width in pitch units 2
False trip protection Yes
Number of fused poles 1
rated residual current 0.03
Suitable for flush-mount installation Yes
IP protection) IP20
rated voltage 230
Rated insulation voltage Ui 264
Rated impulse withstand voltage Uimp 4.0
rated current 10
surge current resistance 1.0
trigger characteristic B
Switching neutral conductor Yes
With locking device Yes
overvoltage category 3
degree of pollution 2
Ambient temperature during operation -25 | 55
installation depth 70.0
Connectable conductor cross-section solid

0.75 | 35.0
