Victron Shunt 6000A/50mV battery monitor

Victron EnergySKU: SHU602050200

Price:
Sale price€219,00 EUR Regular price€259,42 EUR

Tax included Shipping calculated at checkout

Shipping in 8-10 working days

Description

The Victron Shunt 6000A - 50mV is required for current measuring devices with analog or digital displays, as these are typically implemented by measuring a very small voltage across a shunt. In the case of the Victron Shunts 1000A - 6000A, this is 50mV. The following applies: the lower the measurement voltage across the shunt, the less impact it has on the rest of the system's circuit. At 50mV, this provides an excellent value.

The shunt is installed in the line carrying the current to be measured. The small voltage drop across this resistor is evaluated with a measuring device such as the Victron Battery Monitor BMV 700, and values ​​such as the current flow are derived and displayed.
135x60x168

You can find out whether you need a shunt for your display device in the manual for the respective device.

Scope of delivery
1x Victron SHU602050200 shunt 6000A - 50mV
