Victron SmartSolar MPPT 150/85-MC4 VE.Can charge controller

Victron EnergySKU: SCC115085511

Price:
Sale price€365,94 EUR Regular price€587,86 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Smartsolar MPPT 150/85-MC4 VE.Can from Victron Energy belongs to the Dutch premium manufacturer's latest generation of smart solar controllers. Ultra-fast power tracking and automatic power point detection in the event of partial shading are just two of the many highlights of this new device class. Devices in the 150/45 to 150/100 classes are also available in versions with TR screw connections on the solar side of the charge controller. This model also supports parallel operation with other controllers of the same type.
Compared to the BlueSolar series, the Bluetooth module in the SmartSolar family is already integrated into the controller, making the smart dongle obsolete. Also new is the optionally available LCD display, which can be easily plugged onto the SmartSolar 150/85-MC4 as needed. The display then provides all important information about the controller. If required, the MPPT WireBox-XL MC4 from Victron Energy is the ideal addition to your SmartSolar charge controller. It securely covers the cable entries and connection terminals of the controller, thus protecting them from external influences and contact.

key product features
Ultra-fast MPPT tracker of the latest generation ensures the best possible yield even under overcast skies
Automatic detection of the MPP voltage in partial shading ensures a further improvement in yield compared to "simple" MPPT charge controllers
Integrated Bluetooth module for app-supported analysis and configuration of the controller (via free Victron app on compatible devices)
optional LCD display available
VE-Can, the solution for multiple controllers
Integrated VE.Direct data communication port for connecting to additional devices such as the GX Color Control Panel or a Smart BMV battery monitor
high maximum efficiency of 98%
Parallel operation with other 150/85 controllers possible
Adjustable constant charging voltage
Adjustable trickle charge voltage
Suitable for all AGM, GEL, lead-acid calcium-calcium and lithium batteries
fully programmable charging algorithms that can be manually activated and switched later via a switch on the housing
Nominal charging current 85A, 150V maximum PV open circuit voltage
Maximum PV power: 12V 1200W / 24V 2400W / 48V 4900W
integrated protection against battery polarity reversal
multi-stage and adaptive charging algorithm
Remote switching on and off via 2-pin plug possible
Protection class IP 43 for the electronic components and protection class IP 22 for the connection area of ​​the controller
Integrated temperature sensor balances float and constant charge voltage according to temperature
Day/night time control and light dimming option
216x295x103
4.5kg

Smart data communication via VE.Direct and Bluetooth module
Modern Apple and Android smartphones, tablets, MacBooks, and other devices can be connected thanks to the integrated Bluetooth module and the free Victron Connect app. The app can then be used to configure many important functions of the SmartSolar controller. Of course, it also provides all important parameters, such as the current solar yield, in real time.

VE.Can: the solution for multiple controllers
With VE.Can up to 25 devices can be synchronized, with Bluetooth up to 10 devices

Automatic detection of the maximum power point
In the case of partial shading, two or more maximum power points (MPP) may exist on the current-voltage curve. Conventional MPPTs tend to focus on a local MPP, but this may not be the optimal MPP. The innovative algorithm of the SmartSolar device will always maximize energy yield by focusing on the optimal MPP.

High-speed MPPT tracker
Especially under overcast skies, when the light intensity is constantly changing, an extremely fast MPPT controller improves energy yield by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.

comprehensive electronic protection
Protection against reversed battery connection
PV backflow preventer
Protection against overheating of the device
Protection against short circuits
Protection against reversed PV connection

VE.Direct data communication port
VE.Direct in text mode transmits all important parameters every second to other devices connected to the charge controller, thus enabling communication with additional devices such as the GX Color Control system panel. The VE.Direct connection is intended for products where full CANbus integration (VE-Direct) would be too costly. More information about VE.Direct can be found in our Victron Energy brand shop.

Scope of delivery
1x Victron SmartSolar MPPT 150/85-MC4 VE.Can 12V 24V 36V 48V 85A charge controller
Operating instructions
