The Lithium Superpack LSP 12.8/60 by Victron Energy (MPN BAT512060705) is a lithium-iron phosphate battery (LIFEPO4) of the latest generation. With a capacity of 60 AH and a nominal voltage of 12.8 V, it provides solid 256 Wh energy at only 9.5 kilos of weight. The Lithium Superpack series is equipped with a BMS, which takes on the most important tasks when operating a Lifepo4 battery. As a result, the battery can be put into operation immediately without external accessories.
Properties of the Victron LSP 12.8/60 battery
- Victron Energy Part number: BAT512060705
- Energy content: 768Wh, battery native voltage: 12.8 V
- Capacity 60 Ah, 2500 cycles at Dod80%
- Integrated battery management system
- No further external hardware needs for operation
- Clearly lighter than comparable AGM or gel batteries
- supports paralel operation
The LSP 12.8/60– strong lowcost lifepo4 battery in top quality
The Lithium Superpack series is Victrons Basic Lifepo4 series and reduced to the most necessary to offer a model that is particularly designed for a cheap purchase price. Compared to other Victron Lifepo4 series, it has no way of evaluating or analyzing data or analyzing data or options for system integration. But it is very easy in the handling and can be put into operation immediately, without any further accessories. The cycles are also impressive: 2500 cycles are in there with 80 percent discharge and even much more if the unloading is less unloaded.
The integrated BMS
The integrated BMS ensures that the battery cannot be damaged by cell overvoltage or cell sub voltage and ensures the necessary voltage balance under the individual cells. The scope of the BMS is rounded off by protection against over temperature.
Parallel operation possible
The LSP 12.8/60 can be operated in parallel to increase the energy with any number of identical batteries.
scope of delivery
1x Victron BAT512060705 LSP 12.8/60 lithium superpack
