The Phoenix Smart Charger 24/25 (3) IP43 by Victron Energy (MPN PSC242553085) is a powerful battery charger of the latest generation. The device is designed for 24V battery voltage and offers 3 charging outputs, each of which is able to deliver full charging current.
The Phoenix Smart Charger 24/25 (3) IP43 fits into the integrated Bluetooth module in which the Victron smart family is becoming increasingly becoming, which can be perfectly networked and can also be controlled centrally. In addition to the Bluetooth module, there is also a VE.Direct connection and a freely programmable relay. Optionally, the Smart Battery Sense to control the battery temperature compensation can also be connected. The proven five-stage loading algorithm and the possibility to program its own loading algorithm make the Phoenix Smart Charger 24/25 (3) IP43 a universally applicable high-tec battery loader, which can optimally load almost every battery type.
Perfect battery charger for boats and vehicles
Phoenix smart battery charger devices that (1+1) contain in the model name have a main charging output, with a full charging current and a 3A ancillary charging output for charging starter batteries. These models are therefore particularly suitable for the mobile area. The Phoenix Smart models with (3) in the model designation were particularly developed with regard to the needs in the marine area and offer three full power outputs for charging 3 battery benches.
Highlights of the Phoenix Smart Charger 24/25 (3) IP43
- Integrated Bluetooth module
- Integrated VE.Direct connections
- 3x 25a charging outputs are available (maximum 25a charging current)
- Automatic voltage compensation
- adaptive, five -stage loading algorithm
- Variable constant stress phase
- Eye all common types of battery
- Prevention of damage caused by gastroplating thanks
- Reduced aging through storage with storage mode
- Lifepo4 also charges and can be connected to a BMS via optocoupler
- Fully programmable loading algorithm
- Remote on/off
- can be used as a power source
- Optional 2m AC connection cable CEE 7/7 for Smart IP43 Charger
- Technical features of the Phoenix Smart 12/30 (1+1)
- Victron part number: PSC242553085
- Number of batteries: 3 (each output can output the full charging capacity of the device)
- Maximum nominal charging current: 25a, battery voltage: 24V
- High efficiency: 94%
- Protection class: IP43 (electronic components), IP22 (connection area)
- You can find more data with the technical data
Three integrated technologies for all -round healthy batteries
Variable constant voltage phase: always delivers the correct load of charges
With a low battery discharge (e.g. a yacht connected to the country current), a short constant voltage phase is chosen to avoid an overload. After a deep discharge, the constant voltage phase is automatically extended to ensure that the battery is fully charged.
Prevention of damage caused by excessive gastung: Batterysafe mode
In order to shorten the loading time, the highest possible charging current was selected together with a high constant voltage. However, in order for an excessive gas development to be avoided towards the end of the constant trump phase, the charger limits the speed of the voltage climb after the gas voltage has been reached (see also the graphics in the brochure).
Less maintenance and aging in the resting state of the battery: the storage mode
The warehouse mode is always activated if no discharge has been carried out within 24 hours. In storage mode, the loading tension is then reduced to 2.2 V/cell (13.2 V for a 12 V battery) in order to minimize gas development and corrosion on the positive plates. Once a week, the voltage is increased to the level of the gas voltage. This achieves a kind of compensation charge that prevents the electrolystal layering and sulfating - the two main reasons for premature battery failure.
Also perfect for Lifepo4 battery
The Phoenix Smart Charger 24/25 (3) IP43 can be attached to/off by a relay or an optocoupler output with an open collector from a Li-ion BMS to a remote-controlled one/output port. Alternatively, voltage and electricity can also be ruled completely via Bluetooth.
Ve.direct interface, bluetooth and programmable relay
The Phoenix Smart Charger 24/25 (3) IP43 from VICTRON is ideal thanks to the VE.Direct port for a wired data connection with a color control panel, a PC or other devices. Also note the VictronConnect app for Android and iOS, which you can use with any smartphone or tablet to be wireless and read out your Phoenix Charger via Bluetooth. Programmable relay can also be programmed via the VE.Direct interface or a Bluetooth-compatible device in order to trigger an alarm or other events.
Required accessories
Please note that an AC connection cable is required for the connection of the Phoenix Smart Charger 24/25 (3) IP43 to the power grid. This is not included. You can find the right connection cable here:
Frenchman Energy
Frenchman marine
scope of delivery
1x PSC242553085 VICTRON Phoenix Smart Charger 24/25 (3) IP43
1x AC cable clamp
1x operating instructions
data sheet
|
IP protection
|
IP43
|
|
Communication sports
|
Bluetooth, ve.direct
|
|
EAN
|
8719076041658
|
|
Manufacturer part number
|
PSC242553085
|
|
Ambient temperature
|
-20 ° C - +60 ° C
|
|
Battery voltage
|
24V
|
|
Number of charging outputs
|
3
|
|
Battery type adjustable
|
Acid, gel, AGM, LIFEPO4
|
|
Charging
|
Adaptive battery management
|
|
Protective functions
|
Polation on the battery, output ceiling, over temperature
|
|
guarantee
|
2 years
|
|
Temperature compensation
|
Yes, via Smart Battery Sense
|
|
humidity
|
Max. 95 %, not condensing
|
|
Manufacturer
|
Victron Energy
|
|
Weight
|
3.6 kg
|
|
Dimensions (LXBXH)
|
24.9 x 18 x 10 cm
|
