Victron Skylla-i 24/100 (3) 230V Battery Charger 100A 24V (3)

Victron Energy |SKI024100002
GTIN: 8719076026259

Battery Charger Victron Skylla-i 24/100 (3)

three full-power charging outputs
for 24 V systems
charges lead-acid and lithium-ion batteries
can also be used as a power supply

-36%

8887,66 kr.

RRP ~~13992,04 kr.~~

incl. 0% VAT , Shipping costs for orders according to (DE) §12 para. 3 UStG

Choose tax zone / country of delivery

0% VAT for photovoltaics (Section 12 (3) UStG). For further information, please see und here

Low stock level
Ships in 8-12 business days (Mon-Fri) (DE - int. shipments may differ)

Description
GPSR Information

Victron Battery Charger Skylla-i for 24V Batteries

Skylla-i (3): three full-current outputs for charging 3 battery banks.
The Skylla-i (3) features 3 isolated outputs. All outputs can deliver the full rated output current.
The charging voltage can be precisely adjusted to suit any battery system. The charger input is 230 V at 50/60 HZ.
The charging voltage can be measured directly at the battery terminals to compensate for voltage loss due to cable resistance. An external sensor enables battery temperature measurement and corresponding compensation of the charging voltage.

Less maintenance and aging when the battery is idle: Storage mode
Storage mode is activated whenever no discharge has occurred within 24 hours. In storage mode, the float voltage is then reduced to 2.2 V/cell (26.4 V for a 24 V battery) to minimize gassing and corrosion of the positive plates.
Once a week, the voltage is raised back to the absorption voltage threshold to 'refresh' the battery. This achieves a kind of equalization charge that prevents electrolyte stratification and sulfation - the two main causes of premature battery failure.

Robust
The epoxy powder-coated aluminum housing with drip shield and stainless steel brackets withstands even the harshest environmental conditions: heat, humidity and salty air. An acrylic coating protects the circuit boards against corrosion as effectively as possible.
Temperature sensors ensure that the power components are always operated within the specified limits. Under extreme environmental conditions, the output current is automatically reduced if necessary.

Preventing damage caused by excessive gassing: BatterySafe mode
To shorten charging time, the highest possible charging current is combined with a high absorption voltage. However, to prevent excessive gassing toward the end of the bulk phase, the Skylla-i limits the rate of voltage increase once the gassing voltage has been reached.

Suitable for lithium-ion batteries (LiFePo4)
A simple on/off control can be implemented by connecting a relay or optocoupler open-collector output from a Li-Ion BMS to the charger's remote control connection.
Alternatively, voltage and current can be fully controlled by establishing a connection to the galvanically isolated CAN bus connection.

Battery voltage sensor
To compensate for voltage losses caused by cable resistance, the Skylla-i has a voltage sensor in the charging circuit so that the battery always receives the correct charging current.

Use as a power supply
Thanks to the perfectly stabilized output voltage, the Skylla-i can be used as a power supply when no batteries or large buffer capacitors are available.

Technical data

Technical Data Victron Skylla

Shipping weight:

9,50 kg
Item weight:

8,00 kg
