Copy of Victron Centaur Charger 12/60 (3) 12V 60a Battery charger 3 outputs #1

Victron EnergySKU: CCH024060000

Price:
Sale price€799,00 EUR Regular price€1.126,93 EUR

Tax included Shipping calculated at checkout

Shipping in 8-10 working days

Description

The Centaur 12/60 (3) from Victron Energy is a high -quality battery charger for 12V batteries with 3 charging outputs and 60a maximum charging current, which can be distributed to the 3 outputs as desired. Thanks to its wide input voltage area of ​​90-265 V AC, the Centaur 12/60 (3) can be used almost anywhere in the world without special settings. The iuou charging characteristic with a three -stage characteristics ensures a gentle load of your battery (s). The centaur is suitable for charging gel, AGM and bleeding batteries, where the battery type can be selected quickly via a DIP switch on the device's housing.

The Centaur battery charger is completely high frequency. The performance input is electronically regulated in the first performance level via the performance factor. The next stage takes over the galvanic separation and ensures perfect DC voltage at the outputs. The electronic components are protected by a special coating against moisture and dirt to ensure the durability of the device. Three high -performance batteries can be loaded at the same time as this charger.

Important properties of the Centaur 12/60 at a glance

  • For 12V battery voltage, IP20 protection type
  • Victron part number: CCH012060000
  • 3 battery charging outputs, everyone can deliver full 60a charging current (maximum total charging current = 60a)
  • Suitable for batteries with a capacity of 240AH - 600AH
  • three -stage iuou loading
  • Universal 90 - 265V AC input for mains connection, which can work with both 50 Hz and 60 Hz
  • Suitable for charging gel, AGM and lead-acid batteries

Centaur 12/60 (3): Quality without compromises

An aluminum housing with epoxy powder coating, drip protection against sweat water and fastening parts made of stainless steel let the Centaur 12/60 resist the hardest requirements such as heat, moisture and salt-containing atmosphere. The circuit boards are safely protected against corrosion by an acrylic coating. Temperature sensors ensure that all performance components work within specified limits and, if necessary, the output current is automatically reduced in extreme conditions.

Three -level charging characteristic with temperature compensation

Centaur initially loads with a constant current (Bulk) until the charging current has dropped to 70% of the nominal value. This is followed by a fixed four-hour constant voltage phase at the end of which a maintenance loading phase connects. The charging voltage is regulated via the internal temperature sensor (-2MV/° C per cell). The full charging current is distributed over three outputs, with each output releasing full power if only one battery is connected.

Different battery types can be used on Centaur 12/60; The basic setting refers to gel batteries. Other batteries (lyric acid or AGM) can be used after the appropriate setting on the tip switch (bottom left behind the front front panel).

Scope of delivery:

1x Victron Energy CCH012060000 Centaur 12/60 (3) 1x installation instructions
