Victron Orion 24/12-70 with binding posts

Victron EnergySKU: ORI241270030


Due to the holidays and the subsequent inventory, there may be delays in delivery times. Parcel deliveries will be made until December 23 and between the holidays, while freight deliveries will be possible in isolated cases until December 23 and again from January 7, 2026. We apologize for any inconvenience and thank you for your understanding.

Price:
Sale price€134,00 EUR Regular price€142,80 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Victron Orion 24/12-70 with terminal clamps is a modern DC-DC converter and ensures a regulated DC voltage and thus the trouble-free operation of your DC consumers.
The 24/12-70 converts 24V DC to 12V DC and delivers a constant continuous current of 70A, which corresponds to a power output of 840W. Compared to its smaller counterparts, this model features adjustable output voltage via a potentiometer on the device. The adjustable output voltage range is 10-15V. Furthermore, the 24/12-70 can be used for buffer charging your battery and can be connected in parallel with identical units to increase the output current.

Features:
- 24V DC operating voltage, adjustable output voltage 10-15V
- can be connected in parallel with similar devices to increase performance
- can be used for buffer charging
- Battery terminals as connection terminals
- remotely controllable
- temperature-controlled housing ventilation
- Wide input voltage range: 18V – 36V
- 840W power at 70A continuous current
- max. 70A output current
-high efficiency of 92%
- 0.9 kg weight
- 65x88x195

Orion family DC-DC converters generate a clean 12V output voltage and compensate for any line losses as well as fluctuations in battery voltage.

The remote-controlled on/off connection eliminates the need for a high-current switch in the input wiring. The remote-controlled on/off connection can be operated with a power-saving switch or via the motor's run/stop switch (see manual).

Thanks to its adjustable output voltage, it can be used as a battery charger. For example, to charge a 12-volt starter or auxiliary battery in an otherwise 24-volt system.

Can be connected in parallel to increase the output current.
Up to five identical devices can be connected in parallel.

Scope of delivery:
1x Victron ORI241270020 Orion 24/12-70 DC DC Converter 24V to 12V 70A 840W with terminals
