SUNBEAMsystem Nordic 104W Flush

SUNBEAMsystemSKU: N106x54F

Price:
Sale price€271,90 EUR Regular price€289,00 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Nordic series was one of the main reasons for the founding of SUNBEAMsystem: the vision to develop a solar module for northern regions with a perfect balance between price and innovation.
Nordic offers compact yet powerful solar modules, engineered to withstand the demanding conditions at sea. All modules feature a special cell arrangement for improved partial shading performance unmatched by competitors.
The Nordic models with the flush attachment are supplied without mounting holes, making them ideal for glued applications.

-
Powerful and compact
- Improved partial shading performance
- Flush version
- Flexible panel
- walkable coating
- 1.5 m supply cable

- 2-year warranty

All values ​​measured under standard test conditions:
1000W/m2, AM 1.5 at 25 degrees Celsius

Temp coefficient for Isc 0.05 (% / ° C)
Temp coefficient for Voc -0.27 (% / ° C)
Temp coefficient of Pmax -0.38 (% / ° C).
C100 is intended for rigid mounting and should not be used on a tarpaulin. For flexible use, we recommend the SP50Loxx or SP50.

Technical data

Article name

Nordic 104W Flush

Article No.

1970722

Dimensions

1060 x 540 mm

Weight

2 kg

Pmax - Max. power

104 W

Voc - Voltage open circuit

22.69 V

Lsc - short-circuit current

6.34 A

Vmp - Max. system voltage

17.55 V

Imp - Max. Current

5.93 A

Ptol - Power Tolerance

+/- 5%

solar cells

Sunpower

Max sys voltage (including by-pass diode)

30V

Cable length

1.5 m

High shade tolerance

Yes

holes

-

Note: When connecting in series, always pay attention to the permissible max. system voltage of the solar panel
