Victron Orion-Tr 24/48-2.5A (120W)

Victron EnergySKU: ORI244810110

Price:
Sale price€57,12 EUR Regular price€80,92 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Orion-Tr 24/24-17 by
Victron Energy is a galvanically insulated DC-DC voltage converter and ensures a regulated DC voltage and thus for the trouble-free operation of your DC consumers. The compact Orion-Tr DC-DC voltage converter converts the DC input voltage (20-35V) into a controllable 24V output voltage (20-30V) and delivers a constant permanent current of 17A, which corresponds to an output of 400W.

Thanks to the Orion-Tr 24/24-17, you can supply every 24V consumer with exactly the right voltage. The correct voltage is also guaranteed for longer lines, since the Orion can adapt the tension to occurring management losses. With many sensitive electronics devices, compliance with the exact operating tension is essential for a smooth function. The Orion-TR 24/24-17 also dominates the parallel circuit with identical devices and has a remote-controllable input.

Characteristics:
- for 24V battery voltage, adjustable output voltage 20-30V
- Max. 400W output power with a maximum stream of 17a
- Wide input span area: 20-35V
- Protection class IP43, galvanic separation 200V DC between the entrance, output and housing
- can be switched in parallel with similar devices to increase performance
- Remote-controllable on and off switch
- high efficiency of 87%
- 1.6kg
- 130x186x70

Not suitable for charging batteries. Please consider the use of an Orion-Tr Smart to charge the batteries.

    Remote-controllable ON/OFF switches:
    Due to the remote control in/out connection, no high current switch in the input cabling is no longer necessary. The remote control in/out connection can be controlled with a power saving switch or by the run/stop switch of the engine (see manual).

    Scope of delivery:
    1x Victron Energy Ori242441110 Orion-Tr 24/24-17 17A 400W DC-DC voltage converter
