Blue Sea BS 7720 AMI/MIDI fuse block 200A

Blue SeaSKU: BS7720


Due to the holidays and the subsequent inventory, there may be delays in delivery times. Parcel deliveries will be made until December 23 and between the holidays, while freight deliveries will be possible in isolated cases until December 23 and again from January 7, 2026. We apologize for any inconvenience and thank you for your understanding.

Price:
Sale price€43,50 EUR Regular price€49,74 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

Blue Sea BS 7720 AMI/MIDI Fuse Block 200A with Insulation Cover meets ABYC / USCG insulation requirements.

MAIN FEATURES

  • Sealed cover protects fuses from the harsh marine environment
  • Insulation lid meets ABYC/USCG insulation requirements
  • Cable grommets allow access to cables in any direction
  • 200A maximum with 4/0 cable
  • safe for installation in gasoline powered boats

TECHNICAL SPECIFICATIONS

  • Maximum current consumption: 200A
  • Maximum voltage: 32V DC
  • recommended tightening torque of the battery connection bolt: 13.56 Nm
  • Recommended screw tightening torque: 3.05 Nm
  • Battery terminal: M5

Clamp bolt size: 5/16" (M8)
