Forster 20Ah 12.8V LIFEPO4 Heavy Duty Automotive Lithium Battery 600a 240 x 174 x 190mm ~ 3.7.0kg PB-EQ 40AH


Price:
Sale price€579,00 EUR Regular price€690,00 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

12.8V | 20AH | Lithium starter battery | replaced 40Ah lead

Start clear with the latest lithium technology for your start
For the first time Euro 6 Autos) 1zu1 for a Lifepo4 starter battery. We offer you the latest lithium batteries technology ready for installation in a standard battery housing.

Top features:
-Multi-dynamic BMS
-Start-stop function
-Unique & strong function / high current starting output
-very long service life & simple installation
-High cold resistance
-Super light weight
-certified

Multi-dynamic battery management system:
The absolute highlight is the multi-dynamic BMS. This function was originally developed for racing and adapts permanently to the vehicle electronics. It controls all protective functions and ensures maximum security. This BMS protects your battery from overvoltage, over temperature, compensates for the cells when charging and prevents a deep discharge of the battery. This function is unique & always learns.

Start-stop function:
Our LIFEPO4 starter batteries support all vehicle models with the start-stop function. There is also a reliable energy supply here.

Further advantages at an overview:
-Double usable capacity compared to lead batteries
-High quality materials & parts
-Plug & Play
-Suitable battery poles
-Improvement of fuel efficiency
-Higher brightness of the vehicle lighting
-High reliability even with minus degrees


Product quality
The independent German development of the battery management system is the basis for our quality standards. In addition, Forster individual batteries not only checks and documents in production, but also all batteries again on the shipping day before delivery. Our premium starter batteries come fully charged and start your vehicle immediately after installation.

2 year guarantee
As a manufacturer, Forster individual batteries grants a 2 -year guarantee on the battery advertised with the promise of guarantee.

Technical data

Data / order no.: F12-020s EAN 4251847301294 nominal voltage 12.8V technology Lithium lifepo4 Cold test current Ca 600a Operating voltage 11.0V - 14.6V Final pole Motor car standard / plus right at the right circuit 0 (plus pole front right) End polar type for data sheet Pole Dimensions 240 x 174 x 190mm (including connection pole) Installation position arbitrary, standing, lying, side, upright Weight 3.7kg Reference to lead, -Gel, -GM batteries 65D31L, 75D31L, 95D31L, N40L, N70ZL, NX120L, Exide W249BX guarantee 2 years Cell type HDP Heavy Duty Pouch cells Application in parallel circuit Yes, max. 4 pieces of the same type possible Application of series circuit Yes, 2 batteries in series on 24V CAPACITY Capacity @25 ° C 20Ah Capacity @0 ° C 16Ah Capacity @-25 ° C 10Ah Energy content @25 ° C 256Wh LIFESPAN Start cycles > 100,000 (<3Sec.) Cycles / lifespan at 50% DOD >5000 Cycles / lifespan at 70% DOD >3000 Cycles / lifespan at 80% DOD >2500 Topping charging current / 3 seconds. 600a Permanent entertainment current 40A Recommended long -term exposure current > 20a Recommended battery shutdown / system 11.0V LOAD Laddling tension 14.2V - 14.6V Preservation 13.3 - 13.5V Max. Charging current / loading time / not Lima 20Ah / 1 hour. Recommended charging current / not Lima 10Ah Operating temporature in the event of unloading Minus 20 ° C to plus 90 ° C Recommended storage temperature -45 ° C to 70 ° C / max 95% humidity Protection class IP56 storage 60 - 80% / load every 6 months when storing Self -discharge 1.5 - 3% / month Battery management system BMS installed Multi-dynamic BMS Maximum discharge flow / peak 600a Loading programs CCCV / iu / iuou / lead acid Charging protection / control Yes, Deep discharge 8.0V Discharge stream limit (duration) 100a Overvoltage protection 15.6V Balancing Active balancing in every state of charge Short -circuit -resistant Yes Temperature monitoring / protection Yes Remote monitoring integrated with app n/a Bluetooth n/a Conformity specifications Certification UN38.3 | MSDS | CE | Raw Transport classification UN3480
