Fusion MS-RA60 RadioAM/FM/Bluetooth/AUX/DAB+ receiver

FusionSKU: 010-02405-00

Price:
Sale price€261,50 EUR Regular price€299,99 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

Modern, compact and Fusion's most economical marine stereo system to date.

Sources: AM / FM / Bluetooth / AUX / DAB+

The MS-RA60 is our most economical marine stereo yet, featuring modern aesthetics, dual-zone Multi-Zone™ technology, and advanced connectivity in a compact form factor. Designed for high-quality audio entertainment in the harsh marine environment, the MS-RA60 features a wraparound, fog-proof LCD display integrated into the water-resistant black front panel (IPX6 and IPX7).

Features:

Multi-zone technology:
Up to two independent audio zones are available for a customized listening experience on your boat, each with advanced, localized audio options including volume limiting, zone naming, tone control, balance, and more.

IPX6 and IPX7 Ingress Protection : The front panel of the MS-RA60 meets international IPX6 and IPX7 standards for protection against water ingress, ensuring that your product will operate and last in the harsh marine and outdoor environments when properly installed (please refer to the installation guide for further details).

Retrofittable : The MS-RA60 is designed to fit into the MS-RA55 installation profile, so there is no need to modify the existing cutout, reducing the complexity of upgrading your stereo system.

Class-D Amplifier Design: The built-in Class-D amplifier delivers more power with lower current consumption than a standard Class-AB amplifier. This amplifier design ensures higher efficiency and higher output power, allowing you to enjoy your music at higher volumes for longer.

Wireless Software Updates: Over-the-air software updates are now available from your compatible device via BLUETOOTH® using the free Fusion-Link™ app, making it easy to keep the MS-RA60 up to date.

Fusion-Link wireless control via BLUETOOTH and ANT®: Download the free Fusion-Link remote app for BLUETOOTH from the Apple App Store® or Google Play™ and enjoy the freedom of wireless control from your compatible device. Download the free Fusion-Link Lite app from the Connect IQ™ app to enable wireless control via ANT technology from your compatible Garmin watch.

2.3" Monochrome LCD: The monochrome LCD is bonded all around for improved durability and protection against condensation and fogging, and is optimized for daylight viewing.

Modern design and aesthetics: The monochrome LCD is integrated into a black front panel for enhanced visibility and streamlined design. The black front panel blends seamlessly into your dashboard and complements other electronic devices and MFDs for a clean, consistent, and elegant installation.

Built-in DAB module: The built-in DAB module supports the latest DAB and DAB+ broadcasts, allowing you to enjoy high-quality digital radio wherever DAB and DAB+ are supported (Europe and Australia only; does not support traffic and weather information).

Product specifications

Dimensions (WxHxD)

156.9 x 68 x 103.2 mm

Weight

316 g

Water resistance

IPX6 and IPX7 (front panel only when properly installed)

Power supply

10.8-16 VDC

Operating temperature range

0° to 50° C

Power consumption

(max.) 15 A

BLUETOOTH® wireless range

up to 10 m (30 ft)

ANT® Wireless Range

up to 3 m (10 ft)

Radio frequencies/protocols

BLUETOOTH 2.4 GHz @ +12 dBm nominal / ANT 2.4 GHz @ +7 dBm nominal

Compass safety distance

150 mm

Advertisement

2.3" wrap-around monochrome dot matrix LCD

Built-in amplifier

Class-D (minimum impedance 4 ohms)

Top performance

180 W

Top performance

200W max.

Rated output power

(4 ohms) 22W rms x 4 @ 14.4V input, 4 ohms, 10% THD

Fusion Link control

Yes (with compatible Apple® and Android devices)

Fusion-Link Lite control

Yes (with compatible Garmin watch)

Multi-zone technology

2 zones

Wireless BLUETOOTH technology

Yes

ANT Wireless Technology

Yes

DAB+

Yes (integrated DAB tuner)

Multilingual service

Dutch / English / French / German / Italian / Spanish

Software updates

Software updates via wireless BLUETOOTH technology with the Fusion Link app

guarantee

1 year

Sources

AM / FM / BLUETOOTH / AUX x1 / DAB+ (only available in Europe and Australia)

AUX input

One RCA input (AUX)

AM/FM radio

A Motorola antenna connector

Speaker

4 x speaker connections (2 amplified zones)

RCA Pre-Out (left, right and subwoofer)

1 zone (external amplification required)

Line output

Zone 1: L + R (requires external amplification)

Subwoofer output

Zone 1 (external amplification required)
