Victron Orion-Tr 12/24-15A (360W)

Victron EnergySKU: ORI122441110


Due to the holidays and the subsequent inventory, there may be delays in delivery times. Parcel deliveries will be made until December 23 and between the holidays, while freight deliveries will be possible in isolated cases until December 23 and again from January 7, 2026. We apologize for any inconvenience and thank you for your understanding.

Price:
Sale price€218,00 EUR Regular price€255,85 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Victron Energy Orion-TR 12/24-15 is a galvanically isolated DC-DC converter that provides a regulated DC voltage, ensuring trouble-free operation of your DC devices. This compact converter transforms the DC input voltage (10-17V) into an adjustable 24V output voltage (20-30V) and delivers a constant current of 15A, equivalent to 360W.
Thanks to the Orion-Tr 12/24-15, you can supply any 24V device with precisely the right voltage. The correct voltage is guaranteed even with longer cables, as the Orion can adjust the voltage to compensate for line losses. Maintaining the exact operating voltage is essential for the smooth operation of many sensitive electronic devices. Furthermore, the Orion-Tr 12/24-15 supports parallel connection with identical devices and features a remote-controlled on/off switch.

Features:
- for 12V battery voltage, adjustable output voltage 20-30V
- Max. 360W output power at a maximum current of 15A
- Wide input voltage range: 10-17V
- Protection class IP43, galvanic isolation 200V DC between input, output and housing
- can be connected in parallel with similar devices to increase performance
- remote-controlled on/off switch
- High efficiency of 87%
- 1.8kg
- 130x186x80

Not suitable for charging batteries. Please consider using an Orion-Tr Smart to charge the batteries.

remote-controlled on/off switch:
The remote-controlled on/off connection eliminates the need for a high-current switch in the input wiring. The remote-controlled on/off connection can be operated with a power-saving switch or via the motor's run/stop switch (see manual).

Scope of delivery:
1x Victron Energy ORI241224110 Orion-Tr 12/24-15 15A 360W DC-DC voltage converter
