Copy of Victron Smartsolar Mppt 150/70-True Ve.CAN #1

Victron EnergySKU: SCC115070511

Price:
Sale price€329,42 EUR Regular price€527,17 EUR

Tax included Shipping calculated at checkout

Shipping in 8-10 working days

Description

The Smartsolar Mppt 150/70-Tr Ve.Can from Victron Energy, belongs to the latest generation of smart solar controller from the Dutch premium manufacturer and processes a whopping 70a solar power and can flexibly work with 12/24/36/48 V batteries. Ultra-fast power tracking and automatic power point detection in part shading are only 2 of the many highlights of this new device class. The SmartSolar 150/70-Tr. Ve.can Also available as a version with MC4 connections on the solar side of the charge controller instead of screw clamps. This model also dominates parallel operation with other controls of the same type.
Compared to the Bluesolar series, the Bluetooth module is already integrated in the controller at the SmartSolar family, which makes the smart dongle superfluous in this device. Also new is the optionally available LCD display, which on the SmartSolar 150/70-Tr. Ve.can can simply be plugged in if necessary. The display then provides all important information about the controller. If necessary, the MPPT Wirbox-L TR from Victron Energy is the ideal addition to your SmartSolar loader. The cable inputs or the connection terminals of the controller are covered safely and thus protected by external influences and touch.

Essential product features
Ultra-fast MPP tracker of the latest generation ensures the best possible yield even with a covered sky
Nominal charging current 70a, 150V maximum PV empty voltage
Maximum PV performance: 12 V 1000 W / 24 V 2000 W / 48 V 4000 W
Automatic detection of the MPP Tension In the case of partial shading, a further earnings improvement compared to "simpler" MPPT loader
With optional LCD display
Fixed integrated Bluetooth module for app -based analysis and configuration of the controller (via free Victron app on compatible devices)
Optional LCD display available
VE-CAN, the solution for several controllers
Integrated VE.direct data communication sport for connection with additional devices with additional devices the GX Color Control Panel or a Smart BMV battery monitor
high maximum efficiency of 98%
Parallel operation with other 150/70-TR controls possible
Regulatory constant charging voltage
Regulatory conservation charging voltage
Suitable for all AGM, gel, lead-acid calcium calcium and lithium batteries
Fully programmable charging algorithms that can later be activated and switched manually via a switch on the housing
Integrated protection against battery reolving
Multi-level and adaptive loading algorithm
Remote-controlled switching on and off over 2-pin plugs possible
Protection level IP 43 for the electronic components and protection class IP 22 for the connection area of ​​the controller
Integrated temperature sensor compensates for conservation and constant charging voltage after temperature
Day/night-time control and light insulation option
200x250x95
3kg

Smart data communication via VE.Direct and Bluetooth module
Modern Apple and Android Smartphones, Tablets, MacBooks and other devices can be connected thanks to the fixed Bluetooth module and the free VICTRON Connect app. The app can then be used to configure many important functions of the SmartSolar 150/70-MC4. Of course, it also delivers all important parameters such as the current solar yield in real time.

Ve.can: The solution for several controllers
With Ve.CAN, up to 25 devices can be synchronized, with Bluetooth up to 10 devices

Maximum Power Point
In the event of a partial shading, two or more points of maximum performance (MPP) may be available on the electricity voltage curve. Conventional MPTS tend to adjust to a local MPP. However, this may not be the optimal MPP. The innovative algorithm of the SmartSolar 150/70-Tr. Ve.can will always maximize the energy yield by adjusting itself to the optimal MPP.

High-speed MPP tracker
Especially when the sky is covered, when the light intensity is constantly changing, an extremely fast MPPT controller improves the energy yield compared to PWM charging controls by up to 30 % and compared to slower MPPT regulators by up to 10 %.

extensive electronic protection
Protection against flat battery connection
PV backstream lock
Protection against overheating of the device
Protection before short circuits
Protection against flat PV connection

Ve.direct data communication sport
Ve.direct in text mode transmits all important parameters to other devices every second that are coupled with the loader and thus offers the possibility of communication with additional devices system panel GX Color Control. The VE.Direct connection is intended for products in which complete CANBUS integration (VE-Direct) would cause too high costs.

scope of delivery
1x Victron SCC115070411 SmartSolar Mppt 150/70-Tr. Ve.can 12V 24V 48V 70A charge controller
operation manual
