Victron MultiPlus 12/2000/80-32 230V VE.Bus 2000W 3500W inverter 80A charger

Victron EnergySKU: PMP122200000

Price:
Sale price€915,11 EUR Regular price€1.299,48 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Multiplus 12/2000/80-32 from Victron Energy is a combination of a 12V 2000W sine wave inverter and battery charger. The integrated battery charger delivers an impressive 80A, allowing even large batteries to be fully charged quickly when shore/grid power is available. The 12V sine wave voltage converter built into the Multiplus converts your battery power into 230V AC. Thanks to the true sine wave, the power quality is also perfect for sensitive electronic devices. In addition to the two integrated devices, a lightning-fast 32A transfer switch is also installed, which can be used to implement numerous grid-connected solutions. For system integration, the MultiPlus features a VE.Bus port, enabling virtually limitless networking.

Comprehensive and flexible application
Because it features an inverter and charger as well as a lightning-fast 32A transfer switch, it's ideal for mobile homes, boats, or yachts, as well as for grid-connected systems that provide uninterruptible power in the event of grid fluctuations or power outages. It's also ideal for use in grid-connected self-consumption systems that only draw power from the utility when battery power is no longer sufficient, or as a UPS solution where the Multiplus inverters step in when the grid operator's power suddenly fails, thus ensuring an uninterruptible power supply.

Features of the Multiplus 12/2000/80-32
1600W continuous power and 3500W peak power, for 12V battery voltage
Device combination of inverter with transfer switch and 80A battery charger
delivers pure 230V sine voltage and a clean 50Hz frequency
VE.Bus communication port provides extensive networking, system integration, configuration and control options for Victron Multiplus devices
supports three-phase operation (3 identical units of the same model required)
Multiplus devices can be connected in parallel, up to 6 devices can be connected in parallel and the system performance can thus be significantly increased if necessary
PowerControl function enables working with limited generator power as well as limited shore or mains power
PowerAssist function enables “power boost” of generators and shore connection support when needed
Can be used as a UPS solution for uninterruptible power supply, thanks to the integrated transfer switch
Can be used for grid-connected self-consumption systems that only draw power from the grid operator when the battery capacity is no longer sufficient or other programmable events have occurred
Compatible with numerous Victron control and display panels

Massive performance expansion possible
In addition to parallel connection, three units of the same model can also be configured for a three-phase output. But that's not all: Up to six sets of three units can be connected in parallel to achieve a huge charging capacity.

PowerControl – Working with limited generator power, restricted shore or grid power
The MultiPlus is a very powerful battery charger. Therefore, it draws a lot of power from the generator or shore power supply. The MultiControl remote control panel allows you to set the maximum mains or generator current to be drawn. The MultiPlus then takes other connected AC devices into account and uses only the remaining power for charging. This prevents the generator or shore power connection from being overloaded.

PowerAssist – “Power enhancement” of generators and shore connection support
This function adds a new dimension to the PowerControl principle. It allows the MultiPlus to support underpowered alternative sources. Load peaks often occur only for a limited period of time. In such a case, the MultiPlus ensures that insufficient shore power or generator power is immediately compensated for with energy from the battery.

BackUp system : alternating current even in case of power failure
The Multiplus can be used with both off-grid and grid-connected PV systems, as well as other alternative energy systems. Software for grid failure detection is available.

Simple system configuration
If settings on an individual device need to be changed, this can be done within a few minutes using a DIP switch setting procedure.
Parallel and three-phase systems can be configured using the VE.Bus Quick Configure and VE.Bus System Configurator software.

On-site monitoring and control options
Several options are available: Battery Monitor, Multi Control Panel, Ve.Net Blue Power Panel, Color Control Panel, smartphone or tablet (Bluetooth Smart), laptop or computer (USB or RS232).

Remote monitoring and control
Victron Ethernet Remote, Victron Global Remote, and the Color Control Panel enable remote maintenance and monitoring of the MultiPlus. Furthermore, system data can be stored and viewed free of charge on the VRM (Victron Remote Management) website.
