Victron Phoenix Inverter 24/3000 Smart

Victron EnergySKU: PIN242300000

Price:
Sale price€779,45 EUR Regular price€1.095,99 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Phoenix 24/3000 Smart Inverter from Victron Energy is an advanced inverter based on the proven Phoenix series. It offers a continuous power output of 3000VA and is designed for 24V battery voltage. Compared to previous models, the Phoenix Smart series features a Bluetooth module and a VE.Direct output for wireless remote monitoring and system configuration.
The Phoenix 24/3000 Smart is further characterized by its high start-up power and reliability and, thanks to the integrated ECO mode, also plays in the top league of this device class in terms of self-consumption and efficiency.

Features Phoenix 24/3000 Smart
for 24V battery voltage, output voltage range 210C – 245V
Output power (non-linear): 3000VA, 2400W linear continuous load at 25 degrees ambient temperature
6000W peak power handling high starting currents
integrated Bluetooth module and VE.Direct port for wireless monitoring and system integration
designed for high inrush currents
integrated alarm relay, ECO mode
Monitoring of input and output voltage, load and alarms etc. via Bluetooth or VE.Direct
integrated, two-pin plug for connecting an on/off switch (remote control)

Parameters configurable via Bluetooth or VE.Direct
Low battery alarm
Thresholds for switching off and restarting at low battery voltage values
Dynamic shutdown: load-dependent shutdown threshold
Output voltage: 210 - 245V, Frequency: 50 Hz or 60 Hz
Threshold for ECO mode on/off and ECO mode sensor
Alarm relay

high reliability thanks to toroidal transformer topology
Complete bridging, additionally using a toroidal transformer topology, has proven successful for years. The inverters are short-circuit proof and protected against overheating (whether caused by overload or ambient temperature).

very high inrush power
This is required to switch on loads such as voltage converters for LED lamps, halogen lamps or power tools.

Eco Mode
In ECO mode, the inverter switches to standby as soon as the load drops below a preset level. In standby mode, the inverter then switches on for a short period every 2.5 seconds (adjustable). If the load exceeds the preset threshold, the inverter remains switched on.

Remote controlled on/off switching
A remote-controlled on/off switch or a relay contact can be connected to the two-pin connector. Alternatively, the H (left) terminal of the two-pin connector can be connected to a positive battery terminal, or the L (right) terminal of the two-pin connector can be connected to the negative battery terminal (or, for example, to the body of a vehicle).
