Victron Phoenix Inverter 24/3000

Victron EnergySKU: PIN243020000

Price:
Sale price€855,61 EUR Regular price€1.213,80 EUR

Tax included Shipping calculated at checkout

Shipping in 1-3 working days

Description

The Victron Inverter Phoenix 24/3000 is the second largest 24V variant of a Phoenix inverter. Especially in the field of communication, it has some innovative technologies that make the 24/3000 a future-proof investment. The continuous output of this device is 2400W. From a 24V battery, this device generates 230V alternating current for you with a pure sine wave and a clean 50Hz frequency. which also enables the operation of very sensitive electronic devices without compromise. When it comes to self-consumption and efficiency, the voltage converter scores with excellent values. As the icing on the cake, this device class now also masters parallel operation and three-phase operation with other Phoenix inverters of the same series.

VE.Bus RS-485 communication port - far-reaching, new possibilities
All Phoenix inverters of the 12V/24V/48V-3000-5000 series have an RS-485 data port and can use the optional VE Interface MK2-USB to establish a connection to a computer / notebook, which allows you to configure and monitoring opens up whole new possibilities.

Here are some of the most important options that this new feature gives you:
needs-based programming of many parameters such as output voltage, frequency, the upper and lower voltage limits and much more
can be integrated into a computer-aided monitoring and control system
all Phoenix Compact converters can also be used on VENet, Victron Energy's innovative power monitoring network, or other computer-aided control and monitoring systems
easy programming of the integrated relay. The relay can be used, for example, to generate signals in special situations or to start a generator.
Parallel and three-phase operation with other Phoenix inverters possible

The development of the new Phoenix series was aimed uncompromisingly at an inverter with a clean sine wave output and high efficiency. By using the latest hybrid HF technology , Victron was able to develop a quality product with compact dimensions and low weight that can easily deliver any desired power. The SinusMax technology, which also has its place in this series, enables particularly high peak currents when switching on devices of 6000W!

further technical details of the Phoenix 24/3000
2400W continuous power, suitable for all common 24V batteries
true sine wave delivers a precise 50Hz frequency
much higher peak power possible thanks to integrated Sinus-Max technology from Victron
converts 24V DC to 230V AC with pure sine wave
Advanced hybrid HF technology is installed which is significantly more powerful and less susceptible to interference than conventional high-frequency technology
very low self-consumption and high efficiency
integrated energy saving mode
with 2-pin alarm contact which can be used as an output for an on/off remote control
very high starting performance thanks to SinusMax technology

The Sinus-Max technology
A key feature of the SinusMax technology is the particularly high starting power. This is not possible with conventional HF technology. Phoenix inverters are able to cope with the high starting currents, for example from cooling compressors, tool motors and the like. Virtually unlimited power through parallel connection and three-phase operation Up to six inverter units can be connected in parallel to increase performance. A three-phase operation is also possible.

Load transfer to other AC sources: The automatic load transfer switch
For smaller outputs, we recommend the Filax automatic switch. Computers and other sensitive electronic devices can continue to be operated practically without interruption, since the switching times are very short (less than 20 m/sec).
